The E°EXC controller is the all-purpose hardware basis for PLC, motion control and CNC solutions. It supports numerous technology-specific functions and permits the development of sophisticated applications.
Processor performance, interfaces, memory and programming can be selected so as to meet the needs of each individual application. The controllers are available in the following classes:
E°EXC-Controllers at a glance
Technical features & interfaces
| SPS | CODESYS V3 |
| Motion | Function library according to PLCopen |
| CNC | Eckelmann CNC core |
| All-in-one (SPS+Motion+CNC) | ✔ |
| Axes | 32 CNC / 64 Motion (combinable) |
| I/O Modules (local & decentralized) | UBM Series |
| Field busses | EtherCAT, CANopen (for drives and decentralized I/O) |
| USB | ✔ |
| SD card | ✔ |
| Protection class IP | 20 |
| Dimensions (B × H × T) in mm | 100 x 120 x 76 |
| Industry 4.0 | OPC-UA Server |
| Comments | Export variant available (no BAFA export licence required); Safety extension via SLC89 |
| SPS | CODESYS V2 & V3 |
| Motion | Function library according to PLCopen |
| CNC | Eckelmann CNC core |
| All-in-one (SPS+Motion+CNC) | ✔ |
| Axes | 16 CNC / 64 Motion (combinable) |
| I/O Modules (local & decentralized) | On-board I/O (limited number) |
| Field busses | EtherCAT, CANopen (for drives and decentralized I/O) |
| SD card | ✔ |
| Protection class IP | 20 |
| Dimensions (B × H × T) in mm | 267 x 42 x 128 |
| Comments | Available in different versions: |
| • EXC880: Basic version | |
| • EXC882: Analog axis extension | |
| • EXC88x: Customer-specific adaptation | |
| • Export variant available (no BAFA export licence required) |
| SPS | CODESYS V2 |
| Motion | Function library according to PLCopen |
| CNC | Eckelmann CNC core |
| All-in-one (SPS+Motion+CNC) | ✔ |
| Achsen | 16 CNC / 32 Motion (combinable) |
| I/O-Module (lokal & dezentral) | LBM-Series |
| Feldbusse | EtherCAT, CANopen (for drives and decentralized I/O) |
| USB | ✔ |
| SD-Karte | ✔ |
| Schutzart IP | 20 |
| Maße (B × H × T) in mm | 45 × 100 × 115 |
| Industrie 4.0 | |
| Anmerkungen | Compact and export version available no BAFA export license required |
The EXC series can be used both as a pure PLC and in combination with Motion Control and CNC. PLC projects are available for a variety of applications, e.g. milling, drilling, turning, grinding, bending, punching, sawing, cutting (thermal and conventional), etc.
The strengths of Eckelmann controls:
- Innovative CNC core that is continuously developed further
- Extremely short cycle times for highly dynamic applications
- Free progammable PLC (CODESYS)
- CNC software library
- DIN programming
- HMI modular system for intuitive user interfaces
- Motion function library to PLCopen
- Plug-and-play for the integration of components into the control infrastructure, also for supported drive controllers
- OPC-UA server
- All control parameters can be stored on SD card for fast hardware replacement
- Embedded web server
- Robust components with long-term availability
- Integrated development and commissioning environment
- Flexible and application-oriented I/O systems
- Low power consumption and heat (loss) input to switch cabinet
